Dana Spicer 3-3-7041X Slip Yoke 1410 Series 3C3Z-4841-AA, 33/34 splines, 2.086 barrel OD, 8.110 cl to end

Part Number:
3-3-7041X

UPC:

023913238087

Your Cost $695.95

STATUS: IN STOCK - FREE SHIPPING

Dana Spicer 3-3-7041X

Same as OEM FORD Part Number 3C3Z-4841-AA

1410 Series Slip Yoke

Spline/Hole Outside Diameter = 1.551
Number of Splines = 33 splines with one wide space based on a 34 spline output shaft
Series = 1410
Lock up style = OUTSIDE
Universal Joint Width = 4.188
D - Universal Joint Bore = 1.188
J - Center of u-joint bore to End of Slip yoke = 8.110
R - Barrel Outside Diameter = 2.086
Special Notes: Nickel Plated

Dana Spicer 3-3-7041X Slip Yoke 1410 Series 3C3Z-4841-AA, 33/34 splines, 2.086 barrel OD, 8.110 cl to end

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK - FREE SHIPPING

YOUR COST: $695.95

>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<

Dana Spicer 3-3-7041X

Same as OEM FORD Part Number 3C3Z-4841-AA

1410 Series Slip Yoke

Spline/Hole Outside Diameter = 1.551
Number of Splines = 33 splines with one wide space based on a 34 spline output shaft
Series = 1410
Lock up style = OUTSIDE
Universal Joint Width = 4.188
D - Universal Joint Bore = 1.188
J - Center of u-joint bore to End of Slip yoke = 8.110
R - Barrel Outside Diameter = 2.086
Special Notes: Nickel Plated

CLICK HERE : For ALL DANA SPICER Slip Yoke Part Numbers, Specifications and Dimensions
