DANA SPICER 8-3-431KX Slip Yoke 1880 Series 4.156 x 24 splines
|
|
Your Cost
$2,095.95
Sorry, sold out
STATUS:
FACTORY BACK ORDER at this time
|
|
DANA SPICER 8-3-431KX
1880 Series Slip Yoke
- 24 splines
- 4.156 spline diameter
UPC: 023913213831
Part Number: 8-3-431KX
|
DANA SPICER 8-3-431KX Slip Yoke 1880 Series
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY BACK ORDER at this time
YOUR COST:
$2,095.95
>>>>> SPECIAL ORDER PART: This part number is special ordered from the factory and shipped direct to you. It is NOT Cancellable and NOT Returnable. Please make your selection carefully! <<<<<
|
DANA SPICER 8-3-431KX
1880 Series Slip Yoke
- Spline/Hole Outside Diameter = 4.156
- Number of Splines = 24 INVOLUTE
- Series = 1880
- Lock up style = BEARING PLATE
- Outside yoke width = 8.094
- D - Universal Joint Bore = 2.188
- Dust Cap Part Number = D9A
- Dust Cap Style = 3 PIECE SCREW ON
- F - Center of u-joint bore to plug = 1.750
- J - Center of u-joint bore to End of Slip yoke = 5.031
- U-Joint angle 8 degrees
- Use with Dana Spicer 5-308X universal joint
|
|
DANA SPICER 8-3-431KX Slip Yoke 1880 Series
|
|
