Dana Spicer 2-53-1131 MIDSHIP SPLINE Fits 3.0 inch .083 wall tube 1.375 inch Diameter with 16 Splines CL of weld to end 8.908 in.
Part Number:
2-53-1131


UPC:
023913236021
Your Cost $220.95
STATUS:  FACTORY DIRECT - SPECIAL ORDER

DANA SPICER 2-53-1131

  • MIDSHIP SPLINE
  • Use with Center Support Bearing

Spicer
Dana Spicer 2-53-1131 MIDSHIP SPLINE Fits 3.0 inch .083 wall tube 1.375 inch Diameter with 16 Splines CL of weld to end 8.908 in.
Dana Spicer 2-53-1131 MIDSHIP SPLINE Fits 3.0 inch .083 wall tube 1.375 inch Diameter with 16 Splines CL of weld to end 8.908 in.
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT - SPECIAL ORDER
YOUR COST:  $220.95

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 2-53-1131

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 16 Spline SLIP YOKE designed for 1.375 inch diameter spline
    • Fits TUBE DIAMETER = 3.0 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Major SPLINE Diameter = 1.375
    • SPLINES = 16
    • STYLE = 2
    • B = 1.688
    • C = 1.378
    • G = .812
    • K = 8.908
    • L = 2.500
    • Y = 7.848
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)
