Dana Spicer 3-53-1311 MIDSHIP SPLINE Fits 3.5 inch .083 wall tube 1.562 inch Diameter with 16 Splines
Part Number:
3-53-1311


UPC:
023913219000
Your Cost $139.74 Sale Price $126.95
You Save $12.79
STATUS:  SOLD OUT...More Coming Soon

DANA SPICER 3-53-1311

  • MIDSHIP SPLINE
  • Use with Center Support Bearing

Spicer
Dana Spicer 3-53-1311 MIDSHIP SPLINE Fits 3.5 inch .083 wall tube 1.562 inch Diameter with 16 Splines
Dana Spicer 3-53-1311 MIDSHIP SPLINE Fits 3.5 inch .083 wall tubing 1.562 inch Diameter with 16 Splines
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  SOLD OUT...More Coming Soon
YOUR COST:  $139.74 Sale Price $126.95
You Save $12.79

DANA SPICER 3-53-1311

  • MIDSHIP SPLINE
  • Use with Center Support Bearing
  • Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
    • Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
    • Fits TUBE WALL THICKNESS =  .083 inch Tube wall thickness
    • Major SPLINE Diameter = 1.562
    • SPLINES = 16
    • STYLE = 1
    • B = 1.810
    • C = 1.575
    • G = .875
    • K = 8.531
    • L = 5.906
    • Y = 7.410
  • SPECIAL NOTES:
    • Blue GLIDECOAT on Spline for smooth operation and long life (DO NOT REMOVE this coating)



CLICK HERE : For ALL DANA SPICER Spline Part Numbers, Specifications and Dimensions

Dana Spicer 3-53-1311 MIDSHIP SPLINE Fits 3.5 inch .083 wall tube 1.562 inch Diameter with 16 Splines

Dana Spicer 3-53-1311 MIDSHIP SPLINE Fits 3.5 inch .083 wall tubing 1.562 inch Diameter with 16 Splines
