DANA SPICER 5-1-6471X Companion Flange 1610 series 38 Splines 8 holes
|
|
Your Cost
$335.95
Sorry, sold out
STATUS:
FACTORY BACK ORDER at this time
|
|
DANA SPICER 5-1-6471X
- COMPANION FLANGE
- 1610 SERIES
- 38 SPLINES
- Includes (8) 6-73-725 bolts
UPC: 023913216894
Part Number: 5-1-6471X
|
DANA SPICER 5-1-6471X Companion Flange 1610 series 38 Splines 8 holes
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY BACK ORDER at this time
YOUR COST:
$335.95
|
DANA SPICER 5-1-6471X
- COMPANION FLANGE
- 1610 SERIES
- 38 SPLINES
- Includes (8) 6-73-725 bolts
Companion Flanges - Splined Hole |
Model/Part #: 5-1-6471X |
D.) Spline OD |
1.998 |
No. of Splines |
38 I |
C) Pilot Dia. M=male F=female |
5.312-M |
B) Bolt Circle Dia. |
6.125 |
Bolt Hole Dia. (D-drilled T=tapped) |
.375-D |
No. of Holes |
8 |
Drum Pilot Dia. |
.000 |
E) Hub Dia. |
2.750 |
F) Len thru Hole |
2.125 |
G) Flg. Face to Hub End |
4.688 |
Figure |
3 |
Slinger Part No. |
|
Series |
1610 |
|
|
|
|
Assy includes eight 6-73-725 bolts |
|
|
