Dana Spicer 3-40-1411 SPLINE 10.750 inches Fits 3.5 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines
|
|
Your Cost
$193.02 Sale Price $162.60You Save $30.42
STATUS:
FACTORY DIRECT TO YOU
|
|
DANA SPICER 3-40-1411 SPLINE
Fits 3.5 inch .083 wall Driveshaft tubing
1.562 inch Diameter with 16 Splines
UPC: 023913218416
Part Number: 3-40-1411
|
Dana Spicer 3-40-1411 SPLINE 10.750 inches Fits 3.5 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines
|
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS: FACTORY DIRECT TO YOU
YOUR COST:
$193.02 Sale Price $162.60You Save $30.42
|
DANA SPICER SPLINE 3-40-1411
- Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
- Fits TUBE DIAMETER = 3.5 inch OUTSIDE TUBE Diameter
- Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
- Major SPLINE Diameter = 1.562
- SPLINES = 16
- K = 10.750
- L = 3.0
- R = 9.810
|
|
Dana Spicer 3-40-1411 SPLINE 10.750 inches Fits 3.5 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines
|
|
