Driveshaft and Driveline Parts > BUILD IT YOURSELF - PARTS LISTS > 1480 SPLINE and SLIP DRIVESHAFT > BUILD 1480 SERIES with 4 INCH DIAMETER TUBE > SPLINE and SLIP

Dana Spicer 3-40-1381 SPLINE Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

Part Number:
3-40-1381

UPC:

023913236045

Your Cost $206.72

Sorry, sold out

STATUS: OBSOLETE - NO LONGER AVAILABLE

DANA SPICER 3-40-1381 SPLINE

Fits 4 inch .083 wall Driveshaft tubing

1.562 inch Diameter with 16 Splines

Spicer

Dana Spicer 3-40-1381 SPLINE Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

Dana Spicer 3-40-1381 SPLINE Fits 4 inch .083 wall Driveshaft tubing 1.562 inch Diameter with 16 Splines

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: OBSOLETE - NO LONGER AVAILABLE

YOUR COST: $206.72

DANA SPICER SPLINE 3-40-1381

Fits any series 16 Spline SLIP YOKE designed for 1.562 inch diameter spline
Fits TUBE DIAMETER = 4 inch OUTSIDE TUBE Diameter
Fits TUBE WALL THICKNESS = .083 inch Tube wall thickness
Major SPLINE Diameter = 1.562
SPLINES = 16
K = 6.940
L = 3.0
R = 5.810

NOTE: This spline is typically used for 1410 and 1480 series driveshafts.

SCROLL DOWN to see the recommended parts to go with this spline part number.
Great for vehicles that require a larger tube diameter to handle the extra load of carrying heavy cargo or pulling trailers.
Great choice when a 4 inch tube is required for long length driveshafts.

image/jpeg

Dana Spicer 3-40-1381 SPLINE Fits 4 inch .083 wall Driveshaft tube 1.562 inch Diameter with 16 Splines

Dana Spicer 3-40-1381 SPLINE Fits 4 inch .083 wall Driveshaft tubing 1.562 inch Diameter with 16 Splines

You May Also Need These Parts to Complete the Job

DANA SPICER 3-28-507 Weld Yoke 1480 Series to fit 4 inch .083 wall tube Part#: 3-28-507 ~~$52.95~~ $48.95	Dana Spicer 5-188X UNIVERSAL JOINT 1480 series Greaseable U-joint Part#: 5-188X $29.25
Dana Spicer SPL55X Universal Joint 1480 series NON Greaseable u-joint Part#: SPL55X $40.94
