DANA SPICER 3-1-1013-10 Companion Flange 1350/1410 Series Fits 1.750 inch Round Shaft with .375 KEY
Part Number:
3-1-1013-10


UPC:
023913237493
Your Cost $173.95
STATUS:  FACTORY DIRECT - SPECIAL ORDER

DANA SPICER 3-1-1013-10

  • COMPANION FLANGE
  • 1350/1410 Series
  • Same as NEAPCO N3-1-1013-10
Spicer
DANA SPICER 3-1-1013-10 Companion Flange 1350/1410 Series Fits 1.750 inch Round Shaft with .375 KEY
DANA SPICER 3-1-1013-10 Companion Flange 1350/1410 Series Fits 1.750 inch Round Shaft with .375 KEY
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY DIRECT - SPECIAL ORDER
YOUR COST:  $173.95

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 3-1-1013-10

  • COMPANION FLANGE
  • 1350/1410 Series
  • Same as NEAPCO N3-1-1013-10
Companion Flanges - Circular w/ Round Hole Model/Part #:  3-1-1013-10
D.) Bore Dia. 1.750
K) Keyway Width (nom.) .375
C) Pilot Dia. M=male F=female 2.750-F
Figure 1
Bolt Hole Dia. (D-drilled T=tapped) .438 D
Bolt Holes 4
E) Hub Dia. 2.875
F) Flg. Face to Hub End 2.000
A) Flange Diameter 4.562
B) Bolt Circle Diameter 3.750



Denny's Driveshafts Companion Flange Dimensions

DANA SPICER 3-1-1013-10 Companion Flange 1350/1410 Series Fits 1.750 inch Round Shaft with .375 KEY

DANA SPICER 3-1-1013-10 Companion Flange 1350/1410 Series Fits 1.750 inch Round Shaft with .375 KEY
