DANA SPICER 4-1-3891 Companion Flange 1410/1480/1550 Series 1.750 x 10 spline with 2.500 Hub
Part Number:
4-1-3891


UPC:
023913215941
Your Cost $260.95
Sorry, sold out
STATUS:  FACTORY BACK ORDER at this time

DANA SPICER 4-1-3891

  • COMPANION FLANGE
  • 1410/1480/1550 Series
  • 1.750 - 10 SPLINE
Spicer
DANA SPICER 4-1-3891 Companion Flange 1410/1480/1550 Series 1.750 x 10 spline with 2.500 Hub
DANA SPICER 4-1-3891 Companion Flange 1410/1480/1550 Series 1.750 x 10 spline with 2.500 Hub
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  FACTORY BACK ORDER at this time
YOUR COST:  $260.95

>>>>> SPECIAL ORDER PART:  This part number is special ordered from the factory and shipped direct to you.  It is NOT Cancellable and NOT Returnable.  Please make your selection carefully! <<<<<

DANA SPICER 4-1-3891

  • COMPANION FLANGE
  • 1410/1480/1550 Series
  • 1.750 - 10 SPLINE
Companion Flanges - Splined Hole Model/Part #:  4-1-3891
D.) Spline OD 1.750
No. of Splines 10
C) Pilot Dia. M=male F=female 3.750F
B) Bolt Circle Dia. 4.750
Bolt Hole Dia. (D-drilled T=tapped) .500-D
No. of Holes 4
Drum Pilot Dia. 3.750
E) Hub Dia. 2.500
F) Len thru Hole 2.250
G) Flg. Face to Hub End 3.000
Figure 1
Slinger Part No.
Series 1410/1480/1550





image/jpeg
DANA SPICER 4-1-3891 Companion Flange 1410/1480/1550 Series 1.750 x 10 spline with 2.500 Hub

DANA SPICER 4-1-3891 Companion Flange 1410/1480/1550 Series 1.750 x 10 spline with 2.500 Hub
