Jeep - DANA Super 44 REAR - JEEP JK 2007 to 2018

Jeep JK Wrangler with DANA 44 REAR

2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018

Exploded view of Dana 44 Rear axle and differential for 2007 to 2018 Jeep JK Wrangler showing axle, seals, retainers, lock collars, bearings, ring gear bolts, shims, cross shaft pins and locks, positraction plate clutch kits for Track Lok, spider gears, thrust washers, ring and pinion gear sets, diff covers and bolts, gaskets, pinion yokes, pinion nuts, washers and more are all available for the Dana 44 Rear end at Denny's Driveshafts and Driveline Parts.

Jeep JK Dana 44 parts at Denny's Driveshafts





Diagram #
 Part #
 Description   Diagram # Part # Description
  1  ***** Housing - For reference only    25  52380 Diff Large Side Gear Open Diff - See Spider Gear Section
  2  Multiple Gear Set - See Ring and Pinion Gear    26  46948 Thrust washer for Open Diff Small Spider Gear
  3  701140X Inner Pinion Brg Shims    27  2005518 Thrust washer for Open Diff Large Spider Gear
  4  707064X Inner Pinion Bearing Cup and Cone    28  47658 Diff Cross Shaft - Open Diff and Track Loc
  5  46925 Collapsible Spacer - Crush Collar
  6  706123X Outer Pinion Bearing Cup and Cone    24 - 29  2009155  Spider Gear Kit Open Diff Only
  7  42737  Thrust Washer    29  13449  Roll Pin - Open Diff and Track loc
         30  36797  Wheel Bearing Lock Collar
  8  2004101 Pinion Seal
  9  2004431 Pinion - End Yoke    31  565903 Axle Wheel Bearing
 10  30275 Washer for pinion nut    32  52765 Axle Seal
 11  30271 Pinion Yoke Nut    33  2004703 Retainer Ring - Wheel Bearing
 12  42960-1 Diff Cover - Steel    34  2004403 ABS Tone Ring - if required
 12  10023536 Diff Cover - Nodular Iron    35  Multiple  Axle Shaft
 14  34279  Bolts for Diff Cover Qty 10    36  2004789 Wheel Stud
 15   34685 Cover Gasket    37  2007236  Track Lok Diff posi plate and disc kit includes 38, 39, 40
 15  38615 RTV Sealer    39  40835 Clip - Diff Clutch Retainer
 16  701149X or 2007294 Diff Bearing SHIM    41  52381 Gear - Track Loc only
 18 48632-1 Diff Brg Cap Bolt    42  43810  Thrust washer for Trac Lok Diff Small Spider Gear
 19  Multiple Diff Bearing Kit Cup and Cone
 20  2008571 Diff Carrier Case Trac Lok
 20  2008572 Diff Carrier Case Standard Open
 21  703034  Ring Gear Bolt - 1/2 in. thread (13/16 in. hex head)  31/32 in. long
 22  2005193  Actuator Solenoid - Elec Lock
 23  2005192 Thrust Washer - Solenoid Elec Lock
 24  50474 Diff Small Spider Gear - Track Lok
