Neapco N2-4-803-1 weld on end yoke 1310 series 1.375 bore use with 2231-3 splined shaft
$49.79 $47.95 each
|
| Part Number:
N2-4-803-1
|
$49.79 $47.95 each
|
|
Neapco N2-4-803-1
Weld on END Yoke
- 1310 series
- 1.375 inch bore
- Use with 2231-3 splined shaft
Requires machining of bore ID to match diameter of stub OD on 2231-3
|
|
Status: IN STOCK
|
|
|
|
|
Neapco 53-2415 Splined Sleeve 1.625-10 splines 2.010 butt diameter for long travel offroad driveshaft
$63.97 $60.92 each
|
| Part Number:
53-2415
|
$63.97 $60.92 each
|
|
Neapco 53-2415
Splined Sleeve
- 1.625 inch - 10 splines
- 2.010 butt diameter
- Greaseable
- Can be machined to fit 2.0 x .120 wall DOM Tubing.
- Must Machine butt diameter down to 1.771 inches to fit 2.0 x .120 wall tubing
- Can also be machined to fit 2.125 x .188 wall DOM Heavy Wall Tubing
- Use with 2231-3 splined shaft
- Use with N2-4-803-1 weld on end yoke
Great for offroad where long suspension travel is a requirement.
|
|
Status: IN STOCK
|
|
|
|
|
Neapco 53-2415M1 Splined Sleeve 1.625-10 splines 1.850 inch Butt Diameter for long travel offroad driveshaft
$138.55 each
|
| Part Number:
53-2415M1
|
$138.55 each
|
|
Neapco 53-2415M1
Splined Sleeve
- 1.625 inch - 10 splines
- 1.850 butt diameter
- Counterbore your tubing to 1.845 for proper press fit.
Same as 53-2415 except 53-2415M1 has the butt diameter turned down to 1.850 inches
|
|
Status: SOLD OUT...More Coming Soon
|
|
|
|
|
Neapco 2231-3 Splined Shaft 1.625-10 splines for long travel driveshaft
$210.82 $200.78 each
|
| Part Number:
2231-3
|
$210.82 $200.78 each
|
|
Neapco 2231-3
Splined Shaft
- 1.625 inch - 10 splines
- 25.5 inches of available spline
- Use with 53-2415 splined sleeve
- Use with N2-4-803-1 weld on end yoke
Great for offroad where long suspension travel is a requirement.
|
|
Status: IN STOCK
|
|
|
|
|
1350-803 weld on end yoke 1350 series 1.375 bore use with 2231-3 splined shaft
$375.95 each
|
| Part Number:
1350-803
|
$375.95 each
|
|
1350-803
Weld on END Yoke
- 1350 series
- 1.375 inch bore
- Use with 2231-3 splined shaft
|
|
Status: SPECIAL ORDER - 7 to 10 Days lead time
|
|
|
|
|
2.125 x .188 DOM DRIVESHAFT TUBING - 12 INCH LENGTH
$33.00 each
|
| Part Number:
2125-188-12
|
$33.00 each
|
|
DRIVESHAFT TUBING - DOM
12 INCH LENGTH
2.125 x .188 wall HD tubing
- Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
- Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.
- 2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
- .188 WALL THICKNESS (3/16 inch)
- DOM - Drawn over mandrel
- ASTM A513
Great choice for applications requiring additional torsional strength.
Also resists dents from rocks.
|
|
Status: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date
|
|
|
|
|
|
2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH
$66.00 each
|
| Part Number:
2125-188-24
|
$66.00 each
|
|
DRIVESHAFT TUBING - DOM
24 INCH LENGTH
2.125 x .188 wall HD tubing
- Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
- Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.
- 2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
- .188 WALL THICKNESS (3/16 inch)
- DOM - Drawn over mandrel
- ASTM A513
Great choice for applications requiring additional torsional strength.
Also resists dents from rocks.
|
|
Status: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date
|
|
|
|
|
|
2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH - Counterbored to 1.845 ID at one end to fit 53-2415M1 sleeve
$96.80 each
|
| Part Number:
2125-188-24CB
|
$96.80 each
|
|
2125-188-24CB
DRIVESHAFT TUBING - DOM
2.125 x .188 wall HD tubing
- 24 INCH LENGTH - Counterbored to 1.845 inch ID at one end to fit 53-2415M1 sleeve
- Opposite end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
- Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.
- 2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
- .188 WALL THICKNESS (3/16 inch)
- DOM - Drawn over mandrel
- ASTM A513
Great choice for applications requiring additional torsional strength.
Also resists dents from rocks.
|
|
Status: Not available at this time
|
|
|
|
|
2.125 x .188 DOM DRIVESHAFT TUBING - 36 INCH LENGTH
$99.00 each
|
| Part Number:
2125-188-36
|
$99.00 each
|
|
DRIVESHAFT TUBING - DOM
36 INCH LENGTH
2.125 x .188 wall HD tubing
- Each end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
- Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
- Your tube counterbore should be approximately 1.765 for tight press fit.
- 2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
- .188 WALL THICKNESS (3/16 inch)
- DOM - Drawn over mandrel
- ASTM A513
Great choice for applications requiring additional torsional strength.
Also resists dents from rocks.
|
|
Status: IN STOCK - 1 or 2 Business DAY LEAD TIME from Order Date
|
|
|
|
|
DANA SPICER 2-28-1757 Weld Yoke 1310 Series to fit HD 2.125 inch .188 wall tubing
$25.95 each
|
| Part Number:
2-28-1757
|
$25.95 each
|
|
DANA SPICER 2-28-1757
1310 Series Weld Yoke
|
|
Status: IN STOCK
|
|
|
|
|
DANA SPICER 3-28-777 Weld Yoke 1350 Series to fit 2.125 inch .188 wall tubing
$43.95 $39.95 each
|
| Part Number:
3-28-777
|
$43.95 $39.95 each
|
|
DANA SPICER 3-28-777
1350 Series Weld Yoke
|
|
Status: IN STOCK
|
|
|
|
|
Dana Spicer 5-1310X Universal Joint 1310 Series NON Greaseable 3.219 x 1.062 outside snap rings
$19.66 each
|
| Part Number:
5-1310X
|
$19.66 each
|
|
DANA SPICER 5-1310X
- NON GREASEABLE U-Joint
- 1310 series
- A = 3.219 inches wide
- B = 3.219 inches wide
- C = 1.062 inch diameter
- D = 1.062 inch diameter
- Outside snap rings
- 5-1310X is the NON greaseable version of the 5-1310-1X
|
|
Status: IN STOCK
|
|
|
|
|
Dana Spicer 5-1310-1X Universal Joint 1310 Series GREASEABLE 3.219 x 1.062 outside snap rings
$26.95 each
|
| Part Number:
5-1310-1X
|
$26.95 each
|
|
DANA SPICER 5-1310-1X
- GREASEABLE U-Joint
- Grease fitting in end of (1) bearing cap
- 1310 series
- A = 3.219 inches wide
- B = 3.219 inches wide
- C = 1.062 inch diameter
- D = 1.062 inch diameter
- Outside snap rings
- 5-1310-1X is the greaseable version of the 5-1310X
|
|
Status: IN STOCK
|
|
|
