2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH - Counterbored to 1.845 ID at one end to fit 53-2415M1 sleeve

Part Number:
2125-188-24CB

UPC:

Your Cost $96.80

Sorry, sold out

STATUS: Not available at this time

2125-188-24CB

DRIVESHAFT TUBING - DOM

2.125 x .188 wall HD tubing

24 INCH LENGTH - Counterbored to 1.845 inch ID at one end to fit 53-2415M1 sleeve
- Opposite end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
- Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
  - Your tube counterbore should be approximately 1.765 for tight press fit.

2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
.188 WALL THICKNESS (3/16 inch)
DOM - Drawn over mandrel
ASTM A513

Great choice for applications requiring additional torsional strength.

Also resists dents from rocks.

2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH - Counterbored to 1.845 ID at one end to fit 53-2415M1 sleeve

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: Not available at this time

YOUR COST: $96.80

OVERSIZE PACKAGE: Sorry ... this item DOES NOT qualify for Free Shipping!

2125-188-24CB

DRIVESHAFT TUBING - DOM

2.125 x .188 wall HD tubing

24 INCH LENGTH - Counterbored to 1.845 inch ID at one end to fit 53-2415M1 sleeve
- Opposite end ID must be counterbored to fit all splines, weld yokes and cv stud yokes made for 2 inch x .120 wall
- Actual butt diameter of 2.0 x .120 weld yoke, spline or stud yoke is 1.771
  - Your tube counterbore should be approximately 1.765 for tight press fit.

2.125 INCH OUTSIDE DIAMETER (2 1/8 inch)
.188 WALL THICKNESS (3/16 inch)
DOM - Drawn over mandrel
ASTM A513

Great choice for applications requiring additional torsional strength.

Also resists dents from rocks.

PLEASE NOTE: When purchasing more than one piece of tubing you should always CALL in your order so we can quote the shipping cost correctly. Ordering online may show a higher inaccurate cost for multiple piece orders.

2.125 x .188 DOM DRIVESHAFT TUBING - 24 INCH LENGTH - Counterbored to 1.845 ID at one end to fit 53-2415M1 sleeve

You May Also Need These Parts to Complete the Job

Neapco 53-2415M1 Splined Sleeve 1.625-10 splines 1.850 inch Butt Diameter for long travel offroad driveshaft
Part#: 53-2415M1

$138.55
