Dana Spicer 2010948 Companion Flange 29 Spline fits Dana 60, 61, 70 Front or Rear ends can be used with 1310, 1330, 1350 and 1410 series flange yokes

Part Number:
2010948

UPC:

023913235253

Your Cost $59.95

Sorry, sold out

STATUS: SOLD OUT...More Coming Soon

Dana Spicer 2010948

COMPANION FLANGE
Fits Dana 60, 61, 70 FRONT or REAR ends
29 splines
1.875 inches seal surface
1.5 inches length through splined hole
8 mounting holes
- M12-1.75T Metric thread
- Note: Only 4 holes are needed for mounting flange yoke
- See bottom of this page for flange yoke choices
- 4.25 inch bolt circle - diagonally
1.955 inches from flange mounting face to end of splined hole
2 inch male pilot diameter

Can be used with 1310, 1330, 1350 and 1410 flange yokes

Great way to connect any 1310, 1330, 1350 or 1410 series driveshaft to a Dana 60, 61, 70 Front or Rear end

Dana Spicer 2010948 Companion Flange 29 Spline fits Dana 60, 61, 70 Front or Rear ends

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: SOLD OUT...More Coming Soon

YOUR COST: $59.95

Dana Spicer 2010948

COMPANION FLANGE
Fits Dana 60, 61, 70 FRONT or REAR ends
29 splines
1.875 inches seal surface
1.5 inches length through splined hole
8 mounting holes
- M12-1.75T Metric thread
- Note: Only 4 holes are needed for mounting flange yoke
- See bottom of this page for flange yoke choices
- 4.25 inch bolt circle - diagonally
1.955 inches from flange mounting face to end of splined hole
2 inch male pilot diameter

Can be used with 1310, 1330, 1350 and 1410 flange yokes

Great way to connect any 1310, 1330, 1350 or 1410 series driveshaft to a Dana 60, 61, 70 Front or Rear end

Dana Spicer 2010948 Companion Flange 29 Spline fits Dana 60, 61, 70 Front or Rear ends
