Chevrolet > CAMARO 1967 to 2002 > Pinion Yokes > 8.5 inch 10 Bolt 30 spline

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series fits Chevy Camaro GM 8.5 inch 10 Bolt 30 spline strap and bolt style

Part Number:
3-4-8691-1X

UPC:

023913231095

Your Cost $88.95

STATUS: IN STOCK

Dana Spicer 3-4-8691-1X

PINION YOKE

Fits Chevy Camaro Corporate 8.5 inch 10 bolt rear ends
Strap and Bolt style

1350 series
30 SPLINE
SPLINE OD = 1.312
D = 1.188
E = 3.625
Q = 1.156
R = 1.938
S = 3.125

This is the least expensive way to upgrade your Chevy Camaro 8.5 inch 10 bolt pinion yoke.

Spicer

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series fits Chevy Camaro GM 8.5 inch 10 Bolt 30 spline strap and bolt style

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series fits Chevy Camaro GM 8.5 inch 10 Bolt 30 spline strap and bolt style

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK

YOUR COST: $88.95

Dana Spicer 3-4-8681-1

PINION YOKE

Fits Chevy Camaro Corporate 8.5 inch 10 bolt rear ends
Strap and Bolt style

1350 series
30 SPLINE
SPLINE OD = 1.312
D = 1.188
E = 3.625
Q = 1.156
R = 1.938
S = 3.125

This is the least expensive way to upgrade your Chevy Camaro 8.5 inch 10 bolt pinion yoke.

image/jpeg

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series fits Chevy Camaro GM 8.5 inch 10 Bolt 30 spline strap and bolt style

Dana Spicer 3-4-8691-1X Pinion Yoke 1350 Series fits Chevy Camaro GM 8.5 inch 10 Bolt 30 spline strap and bolt style
