Chevrolet > CORVETTE > Pinion Yokes > 1963-1979 with 30 spline pinion > 1310 SERIES

NEAPCO N2-4-GM01X Pinion Yoke U-Bolt style 1310 Series fits 1963 to 1979 Chevrolet Corvette rear end

Part Number:
N2-4-GM01X

UPC:

083869002866

Your Cost $109.48

STATUS: IN STOCK - FREE SHIPPING

NEAPCO N2-4-GM01X

PINION YOKE

Fits Chevrolet Corvette rear end
- 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979
30 splines
1310 Series ... see u-joints at bottom of this page
U-Bolt style pinion yoke ... see u-bolts at bottom of this page

DIMENSIONS

SPLINE OD = 1.328
D = 1.062
E = 3.219
Q = 1.190
R = 1.740
S = 2.59

Neapco

NEAPCO N2-4-GM01X Pinion Yoke U-Bolt style 1310 Series fits 1963 to 1979 Chevrolet Corvette rear end

NEAPCO N2-4-GM01X Pinion Yoke U-Bolt style 1310 Series fits 1963 to 1979 Chevrolet Corvette rear end

Click for Larger Photo

FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE

STATUS: IN STOCK - FREE SHIPPING

YOUR COST: $109.48

NEAPCO N2-4-GM01X

PINION YOKE

Fits Chevrolet Corvette rear end
- 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979
30 splines
1310 Series ... see u-joints at bottom of this page
U-Bolt style pinion yoke ... see u-bolts at bottom of this page

DIMENSIONS

SPLINE OD = 1.328
D = 1.062
E = 3.219
Q = 1.190
R = 1.740
S = 2.59

image/jpeg

NEAPCO N2-4-GM01X Pinion Yoke U-Bolt style 1310 Series fits 1963 to 1979 Chevrolet Corvette rear end

NEAPCO N2-4-GM01X Pinion Yoke U-Bolt style 1310 Series fits 1963 to 1979 Chevrolet Corvette rear end

You May Also Need These Parts to Complete the Job

Dana Spicer 2-94-28X U-Bolt Set fits 1.062 bearing cap diameter 1.416 CL on 1310 or 1330 pinion yokes, transfer case yokes and transmission yokes FORD, CHEVY, GMC, DODGE, JEEP, IHC Part#: 2-94-28X $5.98	Dana Spicer 5-153X Universal Joint Greaseable 1310 series 3.219 x 1.062 outside snap rings Part#: 5-153X $13.10
Dana Spicer 5-1310X Universal Joint 1310 Series NON Greaseable 3.219 x 1.062 outside snap rings Part#: 5-1310X $19.66	Neapco 1-0153 Greaseable universal joint 1310 series 3.219 x 1.062 outside snap rings Part#: 1-0153 ~~$15.76~~ $14.95
