DANA SPICER 3-3-1601KX Slip Yoke 1480 Series 1.562 x 16 spline 6.812 Inches
Part Number:
3-3-1601KX


UPC:
023913212896
Your Cost $71.95
STATUS:  SOLD OUT...More Coming Soon

DANA SPICER 3-3-1601KX

1480 Series Slip Yoke




Spicer
DANA SPICER 3-3-1601KX Slip Yoke 1480 Series 1.562 x 16 spline 6.812 Inches
DANA SPICER 3-3-1601KX Slip Yoke 1480 Series 1.562 x 16 spline 6.812 Inches
FOR FASTER SERVICE, PLEASE ORDER ALL PARTS ONLINE
STATUS:  SOLD OUT...More Coming Soon
YOUR COST:  $71.95

DANA SPICER 3-3-1601KX

1480 Series Slip Yoke

  • Spline/Hole Outside Diameter = 1.562
  • Number of Splines = 16
  • Series = 1480
  • Lock up style = OUTSIDE
  • Universal Joint Width = 4.187
  • D - Universal Joint Bore = 1.375
  • Dust Cap Part Number = D3J
    • Dust Cap Style = 3 PIECE SCREW ON
  • F - Center of u-joint bore to plug = 1.312
  • J - Center of u-joint bore to End of Slip yoke = 6.812





DANA SPICER 3-3-1601KX Slip Yoke 1480 Series 1.562 x 16 spline 6.812 Inches

DANA SPICER 3-3-1601KX Slip Yoke 1480 Series 1.562 x 16 spline 6.812 Inches
